| Application | Liquified Natural Gas |
| Function | Solid Removal
Liquid Coalescer |
| Micron Rating | 0.3
0.5
1
5
10
25
50 |
| Recommended changeout (psi) | 15 psi |
| Recommended changeout (bar) | 1 bar |
| Max Differential pressure (bar) | 3.4 bar |
| Max Differential pressure (psi) | 50 psi |
| Maximum operating temperature (°F) | 275 °F |
| Maximum operating temperature (°C) | 135 °C |
| Cleanable | No |
| Internal diameter - Element (inch) | 3.24 inch |
| Internal diameter - Element (mm) | 82 mm |
| External diameter - Element (inch) | 4.5 inch |
| External diameter - Element (mm) | 114 mm |
| Overall length (Inch) | 72 inch |
| Overall length (mm) | 1829 mm |
| Interchange Information | KING TOOL KT-VSWN (< 1990) |
| Protective Outer Wrap | Yes |
| End Cap Configuration | Open End |
| Filter Material | Fiberglass |
| Seal Material | Buna-N
Viton |
| Merk | Peco Facet |
| Categorie | Filtratie |
| Artikelcode | XPLC-HCP-4V |
| Verpakking | Stuk(s) |
| Bestellen per | 12 |
